4″ Deep Well Submersible Pump 2.0HP

4″ Deep Well Submersible Pump 2.0HP

The 4″ Deep Well Submersible Pump 2.0HP is engineered for reliable and efficient extraction of groundwater from deep wells, boreholes, and underground reservoirs. Equipped with a 1500W copper wire motor, this pump delivers strong performance with an impressive maximum head of 135 meters, making it suitable for high-rise water supply, irrigation systems, and agricultural applications.

Its 17-stage impeller system ensures consistent pressure and smooth water flow, achieving a maximum flow rate of 6.0m³ per hour. The stainless steel pump body offers excellent resistance to corrosion, rust, and wear, ensuring long service life even in demanding water conditions.

Designed with a 4-inch slim body, the pump fits standard deep well casings and features a 1¼-inch outlet for efficient discharge. A 20-meter heavy-duty cable allows deep installation, while the pump is compatible with an external control box (not included), providing flexibility for system integration.

Key Features:

• 1500W (2.0HP) high-performance motor

• Maximum head of 135m for deep wells

• 17-stage impeller for high pressure output

• Durable stainless steel pump body

• Copper wire motor for efficiency and longevity

• Suitable for deep wells, irrigation & water supply

• 4″ slim design fits standard boreholes

• 20m power cable for deep installation



• Technical Specifications

  • Product Type: Deep Well Submersible Pump

  • Pump Size: 4″

  • Voltage: 220–240V ~ 50Hz

  • Rated Power: 1500W (2.0HP)

  • Maximum Head: 135m

  • Maximum Flow Rate: 6.0m³/h

  • Pipe Diameter: 1¼”

  • Impeller: 17-stage

  • Motor Type: Copper wire motor

  • Pump Body Material: Stainless steel

  • Cable Length: 20 meters

  • Control Box: Not included

  • Application: Deep well & borehole water extraction

  • Packaging: Carton box
